FAG NU1096-TB-M1
Price: 0.00 $
Specifications
| Brand | FAG |
| Item Number | NU1096-TB-M1 FAG |
| Manufacturer Part Number | 0815316130000 |
| EAN | 4054366897336 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 480 |
| Outer (D) MM | 700 |
| Width (B) MM | 100 |
| Inner (d) Inch | 18.8976 |
| Outer (D) Inch | 27.5591 |
| Width (B) Inch | 3.937 |
| Weight (kg) | 130 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 100 |
| Radial Static Load Rating C0r (N) | 3100000 |
| Radial Dynamic Load Rating Cr (N) | 1720000 |
| Basic static load rating, radial (C 0r) | "3100000.0000" |
| Limiting speed (n G) | 1490 |
| Reference speed (n u03d1r) | 780 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NU20..-E-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU |
| TB | The Rollers Have A Special Crowning On The Side Surface. Is Not Depending On The Cage Design. The Result Is A Better Lubrication In Between Roller And Rim |
| M1 | Solid Brass Cage, Two Piece, Roller Guided |
