FAG NU1010-XL-M1-C4

FAG NU1010-XL-M1-C4
FAG NU1010-XL-M1-C4 rulman resim 1
FAG NU1010-XL-M1-C4 rulman resim 2
FAG NU1010-XL-M1-C4 rulman resim 3
FAG NU1010-XL-M1-C4 rulman resim 4
FAG NU1010-XL-M1-C4 rulman resim 5
Price: 99.76 $
Specifications
Brand FAG
Item Number NU1010-XL-M1-C4 FAG
Manufacturer Part Number 0167370670040
Also known as NU1010-M1-C4
EAN 4026677512178
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 80
Width (B) MM 16
Inner (d) Inch 1.9685
Outer (D) Inch 3.1496
Width (B) Inch 0.6299
Weight (kg) 0.31 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 41500
Radial Dynamic Load Rating Cr (N) 42500
Limiting speed (n G) 17300
Reference speed (n u03d1r) 7400
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NU..-XL-M1, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU
Suffix description
XL X-Life
M1 Solid Brass Cage, Two Piece, Roller Guided
C4 Bearing Internal Clearance Greater Than C3
