FAG NNU4976-S-M-SP-C3
Price: 0.00 $
Specifications
| Brand | FAG |
| Item Number | NNU4976-S-M-SP-C3 FAG |
| Manufacturer Part Number | 0192340740030 |
| EAN | 4012802293531 |
| Category | Cylindrical Roller Bearing Double Row |
| Inner (d) MM | 380 |
| Outer (D) MM | 520 |
| Width (B) MM | 140 |
| Inner (d) Inch | 14.9606 |
| Outer (D) Inch | 20.4724 |
| Width (B) Inch | 5.5118 |
| Weight (kg) | 91.5 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | W33 |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | SP - Precision Higher than P4S |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 140 |
| Basic static load rating, radial (C 0r) | 3600000 |
| Fatigue load limit, radial (C ur) | 375000 |
| Limiting speed for grease lubrication (n G Grease) | 1380 |
| Limiting speed for oil lubrication (n G Oil) | 1620 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| S | Lubrication Groove And Three Holes In Bearing Outer Ring |
| M | Solid Brass Cage, Roller Guided |
| SP | Special Precision Class For Machine Tool Bearings: Dimensional Accuracy Approximately To P5, Running Accuracy Approximately To P4 |
| C3 | Internal Clearance Larger Than Normal |
IKO NA4976
90.3 kg
380x520x140 mm
FAG NNU4976-S-K-M-SP
91.5 kg
380x520x140 mm
FAG NNU4976-S-M-SP
91.5 kg
380x520x140 mm
INA SL02-4976A
90.5 kg
380x520x140 mm
INA SL014976-A
92.4 kg
380x520x140 mm
RKB NNU4976KM P61 ZB W33
91.5 kg
380x520x140 mm
RKB NNU4976M P63 ZB W33
91.5 kg
380x520x140 mm
Neutral SL02-4976A
90.5 kg
380x520x140 mm
INA SL024976-A
90.5 kg
380x520x140 mm
INA SL014976-ISR6-A
92.4 kg
380x520x140 mm
FAG NNU4976-S-M-W10D-C3
91.5 kg
380x520x140 mm
FAG NNU4976S-M-SP-C3
91.5 kg
380x520x140 mm
FAG NNU4976SM-SP-C3
91.5 kg
380x520x140 mm
FAG NNU4976-S-K-M-C5
91.5 kg
380x520x140 mm
INA SL014976-A-C3
92.4 kg
380x520x140 mm
FAG NNU4976SK-M-SP
91.5 kg
380x520x140 mm
RBC Bearings Industrial SL024976
90.5 kg
380x520x140 mm
IDC/Interprecise Donath GmbH NNC4976V
92.4 kg
380x520x140 mm
IDC/Interprecise Donath GmbH NNCL4976V
90.5 kg
380x520x140 mm
NSK NNU4976KE1CC1P4
91.5 kg
380x520x140 mm
APB/Austria Precision Bearing NNC4976-VX
92.4 kg
380x520x140 mm
Neutral NNU4976KM/SP
91.5 kg
380x520x140 mm
Neutral NNC4976V
92.4 kg
380x520x140 mm
Neutral NNU4976SM SP C3
91.5 kg
380x520x140 mm
