FAG NNU4936-S-M-SP

FAG NNU4936-S-M-SP
FAG NNU4936-S-M-SP rulman resim 1
FAG NNU4936-S-M-SP rulman resim 2
FAG NNU4936-S-M-SP rulman resim 3
Price: 1,808.09 $
Specifications
Brand FAG
Item Number NNU4936-S-M-SP FAG
Manufacturer Part Number 0192332480000
EAN 4012801232036
Category Cylindrical Roller Bearing Double Row
Weight and Dimensions
Inner (d) MM 180
Outer (D) MM 250
Width (B) MM 69
Inner (d) Inch 7.0866
Outer (D) Inch 9.8425
Width (B) Inch 2.7165
Weight (kg) 11.1 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type M - Brass Cage
External Modification W33
Radial Internal Play Cn Normal Internal Play
Precision SP - Precision Higher than P4S
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 69
Radial Static Load Rating C0r (N) 860000
Radial Dynamic Load Rating Cr (N) 405000
Basic static load rating, radial (C 0r) "860000.0000"
Fatigue load limit, radial (C ur) 104000
Limiting speed for grease lubrication (n G Grease) 3000
Limiting speed for oil lubrication (n G Oil) 3550
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
S Lubrication Groove And Three Holes In Bearing Outer Ring
M Solid Brass Cage, Roller Guided
SP Special Precision Class For Machine Tool Bearings: Dimensional Accuracy Approximately To P5, Running Accuracy Approximately To P4
