FAG NN3036-AS-K-M-SP-C2

FAG NN3036-AS-K-M-SP-C2
FAG NN3036-AS-K-M-SP-C2 rulman resim 1
FAG NN3036-AS-K-M-SP-C2 rulman resim 2
Price: 2,543.17 $
Specifications
Brand FAG
Item Number NN3036-AS-K-M-SP-C2 FAG
Manufacturer Part Number 0192314900020
EAN 4012802112849
Category Cylindrical Roller Bearing Double Row
Weight and Dimensions
Inner (d) MM 180
Outer (D) MM 280
Width (B) MM 74
Inner (d) Inch 7.0866
Outer (D) Inch 11.0236
Width (B) Inch 2.9134
Weight (kg) 17.3 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Seal No Seal
Cage Type M - Brass Cage
External Modification No External Modification
Radial Internal Play C2 Internal Play (Less than Cn)
Precision SP - Precision Higher than P4S
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 74
Basic static load rating, radial (C 0r) 1000000
Fatigue load limit, radial (C ur) 118000
Limiting speed for grease lubrication (n G Grease) 2850
Limiting speed for oil lubrication (n G Oil) 3300
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Suffix description
A Cylindrical Roller Bearings, Parts Interchangeable
S Lubrication Groove And Three Holes In Bearing Outer Ring
K Tapered Bore, Taper 1:12
M Solid Brass Cage, Roller Guided
SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1
C2 Bearing Internal Clearance Smaller Than Normal
