FAG NJ2305-E-XL-M1A-C4
Price: 103.54 $
Specifications
| Brand | FAG |
| Item Number | NJ2305-E-XL-M1A-C4 FAG |
| Manufacturer Part Number | 0384536650040 |
| Also known as |
NJ2305-E-M1A-C4 |
| EAN | 4012801575225 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 25 |
| Outer (D) MM | 62 |
| Width (B) MM | 24 |
| Inner (d) Inch | 0.9843 |
| Outer (D) Inch | 2.4409 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 0.39 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 24 |
| Radial Static Load Rating C0r (N) | 54000 |
| Radial Dynamic Load Rating Cr (N) | 66000 |
| Basic static load rating, radial (C 0r) | "54000.0000" |
| Limiting speed (n G) | 21500 |
| Reference speed (n u03d1r) | 8300 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NJ..-E-XL-M1A, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ |
| E | Increased Load Capacity |
| XL | X-Life |
| M1A | Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring |
| C4 | Bearing Internal Clearance Greater Than C3 |
