FAG NJ2217-E-XL-M1A-C3
Price: 304.64 $
Specifications
| Brand | FAG |
| Item Number | NJ2217-E-XL-M1A-C3 FAG |
| Manufacturer Part Number | 0384798500030 |
| Also known as |
NJ2217-E-M1A-C3 |
| EAN | 4012801380515 |
| Category | Cylindrical Roller Bearing Single Row |
| Inner (d) MM | 85 |
| Outer (D) MM | 150 |
| Width (B) MM | 36 |
| Inner (d) Inch | 3.3465 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 1.4173 |
| Weight (kg) | 2.794 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Width (b) mm | 36 |
| Radial Static Load Rating C0r (N) | 275000 |
| Radial Dynamic Load Rating Cr (N) | 255000 |
| Basic static load rating, radial (C 0r) | "275000.0000" |
| Limiting speed (n G) | 8300 |
| Reference speed (n u03d1r) | 3300 |
| ECLASS number | 23-05-09-01 |
| ECLASS2 number | 23-05-09-01 |
| Medias description | Cylindrical roller bearing NJ..-E-XL-M1A, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ |
| E | Increased Load Capacity |
| XL | X-Life |
| M1A | Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring |
| C3 | Internal Clearance Larger Than Normal |
SKF 4217ATN9
2.695 kg
85x150x36 mm
NSK 4217BTNG
2.695 kg
85x150x36 mm
FAG 4217B-TVH
2.695 kg
85x150x36 mm
FAG 4217-B-TVH
2.695 kg
85x150x36 mm
RIV 4217B TNG
2.695 kg
85x150x36 mm
NSK 4217B TNG
2.695 kg
85x150x36 mm
Ransome & Marles LDJ85KM Ransome & Marles
2.47 kg
85x150x36 mm
RHP 4217B TNH
2.695 kg
85x150x36 mm
Ransome & Marles LDJ85K Ransome & Marles
2.47 kg
85x150x36 mm
Neutral 4217
2.47 kg
85x150x36 mm
FAG 2217-M-C3
2.52 kg
85x150x36 mm
FAG 2217-K-M-C3
2.62 kg
85x150x36 mm
FAG 2217M-C3
2.52 kg
85x150x36 mm
FAG 2217-K-M
2.62 kg
85x150x36 mm
FAG 2217-M
2.68 kg
85x150x36 mm
SKF 2217K/C3
2.46 kg
85x150x36 mm
NSK 2217KC3
2.46 kg
85x150x36 mm
Steyr 2217K
2.46 kg
85x150x36 mm
NSK 2217KJC3
2.46 kg
85x150x36 mm
NKE 2217-M
2.68 kg
85x150x36 mm
NTN 2217SK
2.46 kg
85x150x36 mm
