FAG NJ2206-E-XL-M1A-C4

FAG NJ2206-E-XL-M1A-C4
FAG NJ2206-E-XL-M1A-C4 rulman resim 1
FAG NJ2206-E-XL-M1A-C4 rulman resim 2
FAG NJ2206-E-XL-M1A-C4 rulman resim 3
FAG NJ2206-E-XL-M1A-C4 rulman resim 4
Price: 106.36 $
Specifications
Brand FAG
Item Number NJ2206-E-XL-M1A-C4 FAG
Manufacturer Part Number 0190076550040
Also known as NJ2206-E-M1A-C4
EAN 4012801176743
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 62
Width (B) MM 20
Inner (d) Inch 1.1811
Outer (D) Inch 2.4409
Width (B) Inch 0.7874
Weight (kg) 0.291 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 50000
Radial Dynamic Load Rating Cr (N) 58000
Basic static load rating, radial (C 0r) "50000.0000"
Limiting speed (n G) 21200
Reference speed (n u03d1r) 8000
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-M1A, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
C4 Bearing Internal Clearance Greater Than C3
