FAG NJ210-E-XL-M1A-C3

FAG NJ210-E-XL-M1A-C3
FAG NJ210-E-XL-M1A-C3 rulman resim 1
FAG NJ210-E-XL-M1A-C3 rulman resim 2
FAG NJ210-E-XL-M1A-C3 rulman resim 3
FAG NJ210-E-XL-M1A-C3 rulman resim 4
FAG NJ210-E-XL-M1A-C3 rulman resim 5
Price: 102.92 $
Specifications
Brand FAG
Item Number NJ210-E-XL-M1A-C3 FAG
Manufacturer Part Number 0384798000030
Also known as NJ210-E-M1A-C3
EAN 4026677430380
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 90
Width (B) MM 20
Inner (d) Inch 1.9685
Outer (D) Inch 3.5433
Width (B) Inch 0.7874
Weight (kg) 0.552 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type MA - Brass Cage, Centered on Outer Ring
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 69000
Radial Dynamic Load Rating Cr (N) 75000
Basic static load rating, radial (C 0r) "69000.0000"
Limiting speed (n G) 14500
Reference speed (n u03d1r) 6600
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Cylindrical roller bearing NJ..-E-XL-M1A, with cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, type NJ
Suffix description
E Increased Load Capacity
XL X-Life
M1A Solid Brass Cage, Two-Piece, Rib-Guided On Outer Ring
C3 Internal Clearance Larger Than Normal
