FAG N1012-K-PVPA1-SP

FAG N1012-K-PVPA1-SP
FAG N1012-K-PVPA1-SP rulman resim 1
FAG N1012-K-PVPA1-SP rulman resim 2
FAG N1012-K-PVPA1-SP rulman resim 3
FAG N1012-K-PVPA1-SP rulman resim 4
Price: 418.26 $
Specifications
Brand FAG
Item Number N1012-K-PVPA1-SP FAG
Manufacturer Part Number 0731098430000
EAN 4012802773897
Category Cylindrical Roller Bearing Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 95
Width (B) MM 18
Inner (d) Inch 2.3622
Outer (D) Inch 3.7402
Width (B) Inch 0.7087
Weight (kg) 0.42 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Seal No Seal
Cage Type PH - PEEK Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision SP - Precision Higher than P4S
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 18
Radial Static Load Rating C0r (N) 53000
Radial Dynamic Load Rating Cr (N) 43000
Basic static load rating, radial (C 0r) "53000.0000"
Fatigue load limit, radial (C ur) 7100
Limiting speed for grease lubrication (n G Grease) 19200
Limiting speed for oil lubrication (n G Oil) 22600
ECLASS number 23-05-09-01
ECLASS2 number 23-05-09-01
Medias description Super precision cylindrical roller bearings N10..-K-PVPA1-SP, non-locating bearing, with tapered bore, taper 1:12, separable, with cage
Suffix description
K Tapered Bore, Taper 1:12
PVPA1 PEEK Cage Guided On One Side
SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1
