FAG HS7016-C-T-P4S-K5-UL

Specifications

Brand	FAG
Item Number	HS7016-C-T-P4S-K5-UL FAG
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Outer (D) MM	125
Width (B) MM	22
Width (B) Inch	0.8661
Weight (kg)	0.93 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	K5 - P4S + K5
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication	Standard Lubrication

Suffix description

C	15° Or 17° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5	Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL	Single Bearing, Universal, Light Preload
