FAG HS7004-C-T-P4S-UM

Specifications

Brand	FAG
Item Number	HS7004-C-T-P4S-UM FAG
Manufacturer Part Number	0385473920000
EAN	4026677420428
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Outer (D) MM	42
Width (B) MM	12
Width (B) Inch	0.4724
Weight (kg)	0.07 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	P4S Precision (Higher than P4)
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Medias description

Spindle bearings HS70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances

Suffix description

C	15° Or 17° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM	Single Bearing, Universal, Medium Preload
