FAG HCS71909-E-T-P4S-DUL
Price: 777.29 $
Specifications
| Brand | FAG |
| Item Number | HCS71909-E-T-P4S-DUL FAG |
| Manufacturer Part Number | 0380476080000 |
| EAN | 4012801618342 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 45 |
| Outer (D) MM | 68 |
| Width (B) MM | 24 |
| Inner (d) Inch | 1.7717 |
| Outer (D) Inch | 2.6772 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 0.28 kg |
| Seal | 2RU - Two Seals / Non Contact Type |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 12 |
| Basic static load rating, radial (C 0r) | 5400 |
| Limiting speed for grease lubrication (n G Grease) | 32000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
FAG HSS71909-C-T-P4S-DUL
0.294 kg
45x68x24 mm
FAG B71909-E-T-P4S-DUL
0.26 kg
45x68x24 mm
FAG B71909-C-2RSD-T-P4S-DUO
0.26 kg
45x68x24 mm
FAG HSS71909-E-T-P4S-DUL
0.294 kg
45x68x24 mm
SNFA VEB45 9 CE1 DD2
0.26 kg
45x68x24 mm
SKF 71909CD/P4ADGA
0.255 kg
45x68x24 mm
SKF 71909CE/HCP4ADGA
0.26 kg
45x68x24 mm
SNFA SEB45 7 CE1 DDM
0.26 kg
45x68x24 mm
SNFA HB45/S/NS 7 CE3 DDL
0.26 kg
45x68x24 mm
SKF 71909ACD/P4ADGA
0.26 kg
45x68x24 mm
SNFA SEB45 7 CE3 DDF
0.26 kg
45x68x24 mm
SKF 71909CD/P4ADBB
0.26 kg
45x68x24 mm
Timken 3MM9309WI DUM
0.26 kg
45x68x24 mm
SNFA SEB45 7 CE3 DDM
0.26 kg
45x68x24 mm
GMN Paul Müller Industrie S61909C TA UP DUL GMN Paul Müller Industrie
0.255 kg
45x68x24 mm
NSK 7909CTRDUMP3
0.252 kg
45x68x24 mm
Nachi 7909ACYDU/GLP4
0.26 kg
45x68x24 mm
NSK 7909A5TRDUMP3
0.252 kg
45x68x24 mm
NSK 7909CTRDULP3
0.252 kg
45x68x24 mm
NTN BNT909DTUP
0.26 kg
45x68x24 mm
SNR 71909-CV-DUJ74
0.255 kg
45x68x24 mm
NSK 7909A5TRV1VDUMP3
0.252 kg
45x68x24 mm
NSK 7909A5TRDULP3
0.26 kg
45x68x24 mm
Nachi 7909CYDU/GLP4
0.26 kg
45x68x24 mm
FAG HCS71909-C-T-P4S-DUL
0.14 kg
45x68x24 mm
SKF 71909ACD/P4ADBA
0.26 kg
45x68x24 mm
RHP 7909A5 TR DUM P3
0.252 kg
45x68x24 mm
SNFA SEB45 7 CE1 DDF
0.26 kg
45x68x24 mm
SNFA SEB45 7 CE1 DDL
0.26 kg
45x68x24 mm
SKF 71909CD/P4ADGB
0.26 kg
45x68x24 mm
RHP 7909A5 TR DUL P3
0.26 kg
45x68x24 mm
Fafnir 2MM9309WICRDUM
0.26 kg
45x68x24 mm
SNR 71909CV DU J74
0.255 kg
45x68x24 mm
Fafnir 2MMV9309WI CR DUM
0.26 kg
45x68x24 mm
GMN Paul Müller Industrie S61909C TA ABEC7 DUL GMN Paul Müller Industrie
0.255 kg
45x68x24 mm
