FAG HCS7002-C-T-P4S-UL

FAG HCS7002-C-T-P4S-UL
FAG HCS7002-C-T-P4S-UL rulman resim 1
FAG HCS7002-C-T-P4S-UL rulman resim 2
Price: 258.30 $
Specifications
Brand FAG
Item Number HCS7002-C-T-P4S-UL FAG
Manufacturer Part Number 0191800120000
Also known as 2MMVC9102HXVVSUL
EAN 4012801482875
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 15
Outer (D) MM 32
Width (B) MM 9
Inner (d) Inch 0.5906
Outer (D) Inch 1.2598
Width (B) Inch 0.3543
Weight (kg) 0.035 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 9
Basic static load rating, radial (C 0r) 1040
Limiting speed for grease lubrication (n G Grease) 90000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
