FAG HCM71914-C-T-P4S-UL-XL

FAG HCM71914-C-T-P4S-UL-XL
FAG HCM71914-C-T-P4S-UL-XL rulman resim 1
FAG HCM71914-C-T-P4S-UL-XL rulman resim 2
FAG HCM71914-C-T-P4S-UL-XL rulman resim 3
FAG HCM71914-C-T-P4S-UL-XL rulman resim 4
Price: 587.53 $
Specifications
Brand FAG
Item Number HCM71914-C-T-P4S-UL-XL FAG
Manufacturer Part Number 0924550000000
Also known as 71914CEGA/HCP4A
EAN 4054369761535
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 100
Width (B) MM 16
Inner (d) Inch 2.7559
Outer (D) Inch 3.937
Width (B) Inch 0.6299
Weight (kg) 0.255 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Data from Schaeffler (medias)
Width (b) mm 16
Basic static load rating, radial (C 0r) 15000
Limiting speed for grease lubrication (n G Grease) 24200
Limiting speed for oil lubrication (n G Oil) 35300
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
XL X-Life
