FAG HCB7211-E-T-P4S-UL-L207

FAG HCB7211-E-T-P4S-UL-L207
FAG HCB7211-E-T-P4S-UL-L207 rulman resim 1
FAG HCB7211-E-T-P4S-UL-L207 rulman resim 2
FAG HCB7211-E-T-P4S-UL-L207 rulman resim 3
Price: 744.70 $
Specifications
Brand FAG
Item Number HCB7211-E-T-P4S-UL-L207 FAG
Manufacturer Part Number 0387315920000
EAN 4026677587503
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 100
Width (B) MM 21
Inner (d) Inch 2.1654
Outer (D) Inch 3.937
Width (B) Inch 0.8268
Weight (kg) 0.54 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication 2 - High Temperature Grease
Data from Schaeffler (medias)
Width (b) mm 21
Basic static load rating, radial (C 0r) 24000
Limiting speed for grease lubrication (n G Grease) 15000
Limiting speed for oil lubrication (n G Oil) 24000
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
L207 Grease Filling With Arcanol L207 (High Temperature Grease)
