FAG HCB7211-E-T-P4S-UL

FAG HCB7211-E-T-P4S-UL
FAG HCB7211-E-T-P4S-UL rulman resim 1
FAG HCB7211-E-T-P4S-UL rulman resim 2
FAG HCB7211-E-T-P4S-UL rulman resim 3
FAG HCB7211-E-T-P4S-UL rulman resim 4
Price: 645.59 $
Specifications
Brand FAG
Item Number HCB7211-E-T-P4S-UL FAG
Manufacturer Part Number 0385073230000
EAN 4026677054166
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 100
Width (B) MM 21
Inner (d) Inch 2.1654
Outer (D) Inch 3.937
Width (B) Inch 0.8268
Weight (kg) 0.54 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 21
Radial Static Load Rating C0r (N) 24000
Radial Dynamic Load Rating Cr (N) 45000
Basic static load rating, radial (C 0r) "24000.0000"
Limiting speed for grease lubrication (n G Grease) 15000
Limiting speed for oil lubrication (n G Oil) 24000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings HCB72..-E, adjusted, in pairs or sets, contact angle a = 25°, with ceramic balls, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
