FAG HCB7211-C-2RSD-T-P4S-UL-L298

FAG HCB7211-C-2RSD-T-P4S-UL-L298
FAG HCB7211-C-2RSD-T-P4S-UL-L298 rulman resim 1
FAG HCB7211-C-2RSD-T-P4S-UL-L298 rulman resim 2
FAG HCB7211-C-2RSD-T-P4S-UL-L298 rulman resim 3
FAG HCB7211-C-2RSD-T-P4S-UL-L298 rulman resim 4
Price: 965.10 $
Specifications
Brand FAG
Item Number HCB7211-C-2RSD-T-P4S-UL-L298 FAG
Manufacturer Part Number 0848622200000
EAN 4054364482015
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 55
Outer (D) MM 100
Width (B) MM 21
Inner (d) Inch 2.1654
Outer (D) Inch 3.937
Width (B) Inch 0.8268
Weight (kg) 0.55 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 21
Basic static load rating, radial (C 0r) 25000
Limiting speed for grease lubrication (n G Grease) 18000
Suffix description
C 15° Or 17° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
L298 High Temperature Grease That, Due To Its Higher Base Oil Viscosity, Is Used At Continuous Temperatures Up To Approx. +110°C
