FAG HC7014-EDLR-T-P4S-UL

FAG HC7014-EDLR-T-P4S-UL
FAG HC7014-EDLR-T-P4S-UL rulman resim 1
FAG HC7014-EDLR-T-P4S-UL rulman resim 2
FAG HC7014-EDLR-T-P4S-UL rulman resim 3
FAG HC7014-EDLR-T-P4S-UL rulman resim 4
Price: 636.89 $
Specifications
Brand FAG
Item Number HC7014-EDLR-T-P4S-UL FAG
Manufacturer Part Number 0387267180000
EAN 4026677577573
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 110
Width (B) MM 20
Inner (d) Inch 2.7559
Outer (D) Inch 4.3307
Width (B) Inch 0.7874
Weight (kg) 0.61 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication DLR
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 15600
Radial Dynamic Load Rating Cr (N) 23700
Basic static load rating, radial (C 0r) "15600.0000"
Limiting speed for grease lubrication (n G Grease) 20000
Limiting speed for oil lubrication (n G Oil) 32000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
DLR Direct Lube, Integral O-Ring
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
