FAG HC7009-E-T-P4S-UL

FAG HC7009-E-T-P4S-UL
FAG HC7009-E-T-P4S-UL rulman resim 1
FAG HC7009-E-T-P4S-UL rulman resim 2
FAG HC7009-E-T-P4S-UL rulman resim 3
Price: 302.78 $
Specifications
Brand FAG
Item Number HC7009-E-T-P4S-UL FAG
Manufacturer Part Number 0384668800000
EAN 4012801616355
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 75
Width (B) MM 16
Inner (d) Inch 1.7717
Outer (D) Inch 2.9528
Width (B) Inch 0.6299
Weight (kg) 0.24 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 6800
Radial Dynamic Load Rating Cr (N) 11600
Basic static load rating, radial (C 0r) "6800.0000"
Limiting speed for grease lubrication (n G Grease) 30000
Limiting speed for oil lubrication (n G Oil) 48000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
