FAG HC7008-E-T-P4S-UL

FAG HC7008-E-T-P4S-UL
FAG HC7008-E-T-P4S-UL rulman resim 1
FAG HC7008-E-T-P4S-UL rulman resim 2
Price: 279.64 $
Specifications
Brand FAG
Item Number HC7008-E-T-P4S-UL FAG
Manufacturer Part Number 0191785650000
EAN 4012801484114
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 68
Width (B) MM 15
Inner (d) Inch 1.5748
Outer (D) Inch 2.6772
Width (B) Inch 0.5906
Weight (kg) 0.21 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 15
Radial Static Load Rating C0r (N) 5200
Radial Dynamic Load Rating Cr (N) 8900
Basic static load rating, radial (C 0r) "5200.0000"
Limiting speed for grease lubrication (n G Grease) 34000
Limiting speed for oil lubrication (n G Oil) 53000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
