FAG HC7005-E-T-P4S-UL

FAG HC7005-E-T-P4S-UL
FAG HC7005-E-T-P4S-UL rulman resim 1
FAG HC7005-E-T-P4S-UL rulman resim 2
FAG HC7005-E-T-P4S-UL rulman resim 3
Price: 225.33 $
Specifications
Brand FAG
Item Number HC7005-E-T-P4S-UL FAG
Manufacturer Part Number 0384393790000
EAN 4012801483988
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 47
Width (B) MM 12
Inner (d) Inch 0.9843
Outer (D) Inch 1.8504
Width (B) Inch 0.4724
Weight (kg) 0.09 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 12
Radial Static Load Rating C0r (N) 2650
Radial Dynamic Load Rating Cr (N) 5400
Basic static load rating, radial (C 0r) "2700.0000"
Limiting speed for grease lubrication (n G Grease) 53000
Limiting speed for oil lubrication (n G Oil) 80000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
