FAG BAX70-F-T-P4S-DBL

Specifications

Brand	FAG
Item Number	BAX70-F-T-P4S-DBL FAG
Manufacturer Part Number	0707250980000
EAN	4054369888393
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	110
Width (B) MM	36
Inner (d) Inch	2.7559
Outer (D) Inch	4.3307
Width (B) Inch	1.4173
Weight (kg)	1.118 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	P4S Precision (Higher than P4)
Contact Angle	30 degrees
Pairing	DB - O-arrangement, 2
Axial Internal Clearance / Preload	GA - Light Preload
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Width (2B) mm	36
Axial Static Load Rating C0a (N)	64000
Axial Dynamic Load Rating Ca (N)	30000
Limiting speed for grease lubrication (n G Grease)	9000
Limiting speed for oil lubrication (n G Oil)	13000
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Angular contact ball bearing BAX..-F-T-P4S-DBL

Suffix description

F	30° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DBL	Set Of 2 Bearings O-Arrangement, Light Preload
