FAG B7220-C-T-P4S-DUL

FAG B7220-C-T-P4S-DUL
FAG B7220-C-T-P4S-DUL rulman resim 1
FAG B7220-C-T-P4S-DUL rulman resim 2
FAG B7220-C-T-P4S-DUL rulman resim 3
FAG B7220-C-T-P4S-DUL rulman resim 4
Price: 1,494.06 $
Specifications
Brand FAG
Item Number B7220-C-T-P4S-DUL FAG
Manufacturer Part Number 0380475000000
Also known as 7220CD/P4ADGA
EAN 4012801618199
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 68
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 2.6772
Weight (kg) 6.42 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 34
Basic static load rating, radial (C 0r) 88000
Limiting speed for grease lubrication (n G Grease) 7500
Limiting speed for oil lubrication (n G Oil) 12000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL Set Of 2 Universal Bearings, Light Preload
