FAG B7216-C-T-P4S-UM

FAG B7216-C-T-P4S-UM
FAG B7216-C-T-P4S-UM rulman resim 1
FAG B7216-C-T-P4S-UM rulman resim 2
FAG B7216-C-T-P4S-UM rulman resim 3
Price: 438.41 $
Specifications
Brand FAG
Item Number B7216-C-T-P4S-UM FAG
Manufacturer Part Number 0191571340000
Also known as 7216CDGB/P4A
EAN 4026677068453
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 80
Outer (D) MM 140
Width (B) MM 26
Inner (d) Inch 3.1496
Outer (D) Inch 5.5118
Width (B) Inch 1.0236
Weight (kg) 1.43 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 26
Basic static load rating, radial (C 0r) 55000
Limiting speed for grease lubrication (n G Grease) 10000
Limiting speed for oil lubrication (n G Oil) 17000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
