FAG B7212-E-T-P4S-QBCL

Specifications

Brand	FAG
Item Number	B7212-E-T-P4S-QBCL FAG
Manufacturer Part Number	0219439150000
Also known as	7212ACD/P4AQBCA
EAN	4026677972514
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Inner (d) MM	60
Outer (D) MM	110
Width (B) MM	88
Inner (d) Inch	2.3622
Outer (D) Inch	4.3307
Width (B) Inch	3.4646
Weight (kg)	3.18 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	P4S Precision (Higher than P4)
Contact Angle	25 degrees
Pairing	QBC - O-arrangement, 4
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Width (b) mm	22
Basic static load rating, radial (C 0r)	29500
Limiting speed for grease lubrication (n G Grease)	12000
Limiting speed for oil lubrication (n G Oil)	19000
ECLASS number	23-05-08-03
ECLASS2 number	23-05-08-03

Suffix description

E	25° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S	Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
QBCL	Four Bearings In O Arrangement <<>>
