FAG B7210-C-T-P4S-UL

FAG B7210-C-T-P4S-UL
FAG B7210-C-T-P4S-UL rulman resim 1
FAG B7210-C-T-P4S-UL rulman resim 2
FAG B7210-C-T-P4S-UL rulman resim 3
FAG B7210-C-T-P4S-UL rulman resim 4
FAG B7210-C-T-P4S-UL rulman resim 5
Price: 234.63 $
Specifications
Brand FAG
Item Number B7210-C-T-P4S-UL FAG
Manufacturer Part Number 0190036250000
Also known as 7210CDGA/P4A
EAN 4012801168137
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 90
Width (B) MM 20
Inner (d) Inch 1.9685
Outer (D) Inch 3.5433
Width (B) Inch 0.7874
Weight (kg) 0.46 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 22400
Radial Dynamic Load Rating Cr (N) 43000
Basic static load rating, radial (C 0r) "22400.0000"
Limiting speed for grease lubrication (n G Grease) 16000
Limiting speed for oil lubrication (n G Oil) 26000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
