FAG B7209-E-T-P4S-DUL
Price: 454.74 $
Specifications
| Brand | FAG |
| Item Number | B7209-E-T-P4S-DUL FAG |
| Manufacturer Part Number | 0380675280000 |
| Also known as |
7209ACD/P4ADGA |
| EAN | 4012801753975 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 45 |
| Outer (D) MM | 85 |
| Width (B) MM | 38 |
| Inner (d) Inch | 1.7717 |
| Outer (D) Inch | 3.3465 |
| Width (B) Inch | 1.4961 |
| Weight (kg) | 0.8 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 19 |
| Basic static load rating, radial (C 0r) | 16900 |
| Limiting speed for grease lubrication (n G Grease) | 15000 |
| Limiting speed for oil lubrication (n G Oil) | 24000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
