FAG B7206-C-T-P4S-DUL
Price: 314.95 $
Specifications
| Brand | FAG |
| Item Number | B7206-C-T-P4S-DUL FAG |
| Manufacturer Part Number | 0191561030000 |
| Also known as |
7206CD/P4ADGA |
| EAN | 4012801460477 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 30 |
| Outer (D) MM | 62 |
| Width (B) MM | 32 |
| Inner (d) Inch | 1.1811 |
| Outer (D) Inch | 2.4409 |
| Width (B) Inch | 1.2598 |
| Weight (kg) | 0.4 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 16 |
| Radial Static Load Rating C0r (N) | 10400 |
| Radial Dynamic Load Rating Cr (N) | 23100 |
| Basic static load rating, radial (C 0r) | "10400.0000" |
| Limiting speed for grease lubrication (n G Grease) | 24000 |
| Limiting speed for oil lubrication (n G Oil) | 38000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
