FAG B7204-C-T-P4S-DUL
Price: 238.37 $
Specifications
| Brand | FAG |
| Item Number | B7204-C-T-P4S-DUL FAG |
| Manufacturer Part Number | 0191559300000 |
| Also known as |
7204CD/P4ADGA |
| EAN | 4012801459969 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 20 |
| Outer (D) MM | 47 |
| Width (B) MM | 28 |
| Inner (d) Inch | 0.7874 |
| Outer (D) Inch | 1.8504 |
| Width (B) Inch | 1.1024 |
| Weight (kg) | 0.22 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 14 |
| Radial Static Load Rating C0r (N) | 8000 |
| Radial Dynamic Load Rating Cr (N) | 17200 |
| Basic static load rating, radial (C 0r) | "8000.0000" |
| Limiting speed for grease lubrication (n G Grease) | 32000 |
| Limiting speed for oil lubrication (n G Oil) | 48000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
FAG 6204-A30-50-N13BA
0.212 kg
20x47x28 mm
SLF Fraureuth 6204ZR-P63-N13BA-L74
0.206 kg
20x47x28 mm
FAG B7204-E-T-P4S-DUL
0.22 kg
20x47x28 mm
SKF 7204ACD/P4ADBA
0.2 kg
20x47x28 mm
SKF 7204CD/PA9ADBA
0.2 kg
20x47x28 mm
SKF 7204ACD/P4ADBC
0.2 kg
20x47x28 mm
SKF 7204CD/P4ADGA
0.2 kg
20x47x28 mm
SKF 7204ACD/P4ADGA
0.2 kg
20x47x28 mm
Timken 2MM204WICRDUM
0.2 kg
20x47x28 mm
RHP 7204C T DUL P4
0.2 kg
20x47x28 mm
NSK 7204ATYP4 DB/GN
0.2 kg
20x47x28 mm
NSK 7204ATYP5DF/C8
0.2 kg
20x47x28 mm
NSK 7204A5TRDULP3
0.2 kg
20x47x28 mm
NSK 7204ATYNDFMP5
0.2 kg
20x47x28 mm
NSK 7204CTRDUMP3
0.214 kg
20x47x28 mm
Nachi 7204CYDU/GLP4
0.2 kg
20x47x28 mm
NSK 7204BWDFC8
0.2 kg
20x47x28 mm
NTN 7204CGD2/GLP4
0.2 kg
20x47x28 mm
Fafnir 2MMV204WI CR DUL
0.2 kg
20x47x28 mm
NSK 7204CTRDULP3
0.214 kg
20x47x28 mm
GMN Paul Müller Industrie S6204E TA ABEC7 DUL GMN Paul Müller Industrie
0.2 kg
20x47x28 mm
GMN Paul Müller Industrie BNT6204C TAM UP RI DUL GMN Paul Müller Industrie
0.21 kg
20x47x28 mm
NSK 7204A5TRDUMP3
0.2 kg
20x47x28 mm
NSK 7204CTYNDULP4
0.2 kg
20x47x28 mm
SNR 7204HG1DUJ74
0.2 kg
20x47x28 mm
FAG B7204C-T-P4S-DUL
0.22 kg
20x47x28 mm
SNFA E220 7 CE3 DDM
0.2 kg
20x47x28 mm
Timken 2MM204WICRDUL
0.2 kg
20x47x28 mm
RHP B7204X2 TADUL EP7 T
0.2 kg
20x47x28 mm
RHP 7204T DU EP7 YZ
0.2 kg
20x47x28 mm
SKF 7204C/P4DBB
0.2 kg
20x47x28 mm
RHP 7204C TR DUM P3
0.214 kg
20x47x28 mm
Koyo (JTEKT) 7204C DBL FG P4
0.2 kg
20x47x28 mm
NSK 7204C TR DUL P3
0.214 kg
20x47x28 mm
NSK 7204ATYP4DB/GN
0.2 kg
20x47x28 mm
