FAG B7203-C-T-P4S-DUL
Price: 226.35 $
Specifications
| Brand | FAG |
| Item Number | B7203-C-T-P4S-DUL FAG |
| Manufacturer Part Number | 0191558750000 |
| Also known as |
7203CD/P4ADGA |
| EAN | 4012801459914 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 17 |
| Outer (D) MM | 40 |
| Width (B) MM | 24 |
| Inner (d) Inch | 0.6693 |
| Outer (D) Inch | 1.5748 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 0.14 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 12 |
| Radial Static Load Rating C0r (N) | 5800 |
| Radial Dynamic Load Rating Cr (N) | 13000 |
| Basic static load rating, radial (C 0r) | "5800.0000" |
| Limiting speed for grease lubrication (n G Grease) | 38000 |
| Limiting speed for oil lubrication (n G Oil) | 56000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B72..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
FAG B7203-E-T-P4S-DUL
0.14 kg
17x40x24 mm
SKF 7203CD/P4ADBB
0.124 kg
17x40x24 mm
SNFA E217 7PE1 DUL
0.124 kg
17x40x24 mm
SKF 7203CD/P4ADGA
0.124 kg
17x40x24 mm
SNFA E217 7PE3 DUL
0.124 kg
17x40x24 mm
NSK 7203BWDB
0.128 kg
17x40x24 mm
NSK 7203CTRDUMP3
0.124 kg
17x40x24 mm
NSK 7203CTRDULP3
0.124 kg
17x40x24 mm
NSK 7203ATYNP4 DB/M
0.14 kg
17x40x24 mm
NSK 7203CTYNDULP4
0.124 kg
17x40x24 mm
GMN Paul Müller Industrie S6203C TA ABEC7 DUL GMN Paul Müller Industrie
0.124 kg
17x40x24 mm
Nachi 7203CY DU GL P4
0.124 kg
17x40x24 mm
Fafnir 3MMV203WI CR DUL
0.124 kg
17x40x24 mm
NSK 7203A5TRDUMP3
0.124 kg
17x40x24 mm
NSK 7203A5TRDULP3
0.124 kg
17x40x24 mm
FAG B7203C-T-P4S-DUL
0.14 kg
17x40x24 mm
FAG B7203-E-2RSD-T-P4S-DUL
0.13 kg
17x40x24 mm
RHP B7203X2 TADUL EP7 T
0.124 kg
17x40x24 mm
Barden 203HDL
0.14 kg
17x40x24 mm
RHP 7203C T DUL P4
0.124 kg
17x40x24 mm
SKF 7203ACD/P4ADGB
0.124 kg
17x40x24 mm
SKF 7203C/P4DGA
0.124 kg
17x40x24 mm
SKF 7203CD/P4ADBA
0.124 kg
17x40x24 mm
RHP 7203CTRDULP3
0.124 kg
17x40x24 mm
SKF 7203ACD/P4ADGA
0.124 kg
17x40x24 mm
SKF 7203CD/P4ADGB
0.124 kg
17x40x24 mm
RHP B7203X2 TA DUL EP7
0.124 kg
17x40x24 mm
SNFA E217 7CE1 DUL
0.124 kg
17x40x24 mm
Timken 2MMV203WIDUL
0.124 kg
17x40x24 mm
Fafnir 2MM203WIDUL
0.124 kg
17x40x24 mm
NSK 7203C TR DUL P3
0.124 kg
17x40x24 mm
NSK 7203A5 TR DUM P3
0.124 kg
17x40x24 mm
IBC Bearings 7203-C-T-P4A-DBL
0.124 kg
17x40x24 mm
Nachi 7203CYDU/GLP4
0.124 kg
17x40x24 mm
NSK 7203ATYNDBMP4
0.14 kg
17x40x24 mm
