FAG B7201-E-T-P4S-UL

FAG B7201-E-T-P4S-UL
FAG B7201-E-T-P4S-UL rulman resim 1
FAG B7201-E-T-P4S-UL rulman resim 2
FAG B7201-E-T-P4S-UL rulman resim 3
Price: 103.98 $
Specifications
Brand FAG
Item Number B7201-E-T-P4S-UL FAG
Manufacturer Part Number 0191558240000
Also known as 7201ACDGA/P4A
EAN 4012801459655
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 12
Outer (D) MM 32
Width (B) MM 10
Inner (d) Inch 0.4724
Outer (D) Inch 1.2598
Width (B) Inch 0.3937
Weight (kg) 0.04 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 10
Radial Static Load Rating C0r (N) 3750
Radial Dynamic Load Rating Cr (N) 8800
Basic static load rating, radial (C 0r) "3750.0000"
Limiting speed for grease lubrication (n G Grease) 45000
Limiting speed for oil lubrication (n G Oil) 67000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B72..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
