FAG B7200-E-2RSD-T-P4S-UL

FAG B7200-E-2RSD-T-P4S-UL
FAG B7200-E-2RSD-T-P4S-UL rulman resim 1
FAG B7200-E-2RSD-T-P4S-UL rulman resim 2
Price: 136.49 $
Specifications
Brand FAG
Item Number B7200-E-2RSD-T-P4S-UL FAG
Manufacturer Part Number 0386168740000
EAN 4026677727107
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 10
Outer (D) MM 30
Width (B) MM 9
Inner (d) Inch 0.3937
Outer (D) Inch 1.1811
Width (B) Inch 0.3543
Weight (kg) 0.03 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 9
Radial Static Load Rating C0r (N) 2800
Radial Dynamic Load Rating Cr (N) 6600
Basic static load rating, radial (C 0r) "2800.0000"
Limiting speed for grease lubrication (n G Grease) 50000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B72..-E-2RSD, adjusted, in pairs or sets, contact angle a = 25°, lip seals on both sides, non-contact, restricted tolerances
Suffix description
E 25° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
