FAG B71938-E-T-P4S-UL
Price: 2,468.87 $
Specifications
| Brand | FAG |
| Item Number | B71938-E-T-P4S-UL FAG |
| Manufacturer Part Number | 0191555650000 |
| Also known as |
71938ACDGA/P4A |
| EAN | 4012801459105 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 190 |
| Outer (D) MM | 260 |
| Width (B) MM | 33 |
| Inner (d) Inch | 7.4803 |
| Outer (D) Inch | 10.2362 |
| Width (B) Inch | 1.2992 |
| Weight (kg) | 4.29 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 33 |
| Radial Static Load Rating C0r (N) | 144000 |
| Radial Dynamic Load Rating Cr (N) | 164000 |
| Basic static load rating, radial (C 0r) | "144000.0000" |
| Limiting speed for grease lubrication (n G Grease) | 4500 |
| Limiting speed for oil lubrication (n G Oil) | 6700 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearing B719..-E-T-P4S, with steel balls |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL | Single Bearing, Universal, Light Preload |
FAG 61938-C3
4.14 kg
190x260x33 mm
SKF 61938MA
5.25 kg
190x260x33 mm
SKF 61938MA/C3
5.25 kg
190x260x33 mm
NSK 6938MC3
4.14 kg
190x260x33 mm
ZVL 61938MA
5.25 kg
190x260x33 mm
Rollway 61938M C3
4.14 kg
190x260x33 mm
FAG 61938M-C3
4.14 kg
190x260x33 mm
FAG 804557AB
4.14 kg
190x260x33 mm
FAG 61938-C3
4.14 kg
190x260x33 mm
RKB 61938MB
5.25 kg
190x260x33 mm
NTN 6938C3 L1
4.14 kg
190x260x33 mm
RKB 61938MA C3
5.25 kg
190x260x33 mm
FAG 61938-C4
4.14 kg
190x260x33 mm
FAG 61938-M
5.25 kg
190x260x33 mm
FAG 6938C3
4.14 kg
190x260x33 mm
FAG 61938M
5.25 kg
190x260x33 mm
NKE 61938-C3
4.14 kg
190x260x33 mm
Steyr 61938M
5.25 kg
190x260x33 mm
ZEN 61938M
5.25 kg
190x260x33 mm
FAG B71938-C-T-P4S-UL
4.31 kg
190x260x33 mm
FAG B71938-E-T-P4S-K5-UL
4.29 kg
190x260x33 mm
FAG B71938C-T-P4S-UL
4.31 kg
190x260x33 mm
SKF 71938ACD/P4A
4.35 kg
190x260x33 mm
NSK 7938CTSULP3
4.35 kg
190x260x33 mm
FAG B71938E-T-P4S-UL
4.29 kg
190x260x33 mm
SKF 71938ACDGA/P4A
4.35 kg
190x260x33 mm
NSK 7938A5 TR SUL P3
4.35 kg
190x260x33 mm
NSK 7938C T SUL P3
4.35 kg
190x260x33 mm
FAG B71938-E-T-P4S
4.29 kg
190x260x33 mm
SKF 71938CDGB/P4A
4.35 kg
190x260x33 mm
