FAG B71936-C-T-P4S-UM
Price: 2,069.97 $
Specifications
| Brand | FAG |
| Item Number | B71936-C-T-P4S-UM FAG |
| Manufacturer Part Number | 0387751150000 |
| Also known as |
71936CDGB/P4A |
| EAN | 4026677649874 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 180 |
| Outer (D) MM | 250 |
| Width (B) MM | 33 |
| Inner (d) Inch | 7.0866 |
| Outer (D) Inch | 9.8425 |
| Width (B) Inch | 1.2992 |
| Weight (kg) | 4.13 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 33 |
| Basic static load rating, radial (C 0r) | 146000 |
| Limiting speed for grease lubrication (n G Grease) | 5300 |
| Limiting speed for oil lubrication (n G Oil) | 8000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UM | Single Bearing, Universal, Medium Preload |
