FAG B71924-E-T-P4S-UM

FAG B71924-E-T-P4S-UM
FAG B71924-E-T-P4S-UM rulman resim 1
FAG B71924-E-T-P4S-UM rulman resim 2
Price: 852.51 $
Specifications
Brand FAG
Item Number B71924-E-T-P4S-UM FAG
Manufacturer Part Number 0191551150000
Also known as 71924ACDGB/P4A
EAN 4026677628114
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 120
Outer (D) MM 165
Width (B) MM 22
Inner (d) Inch 4.7244
Outer (D) Inch 6.4961
Width (B) Inch 0.8661
Weight (kg) 1.16 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 22
Basic static load rating, radial (C 0r) 56000
Limiting speed for grease lubrication (n G Grease) 7000
Limiting speed for oil lubrication (n G Oil) 11000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
