FAG B71924-C-T-P4S-DUL

FAG B71924-C-T-P4S-DUL
FAG B71924-C-T-P4S-DUL rulman resim 1
FAG B71924-C-T-P4S-DUL rulman resim 2
FAG B71924-C-T-P4S-DUL rulman resim 3
FAG B71924-C-T-P4S-DUL rulman resim 4
FAG B71924-C-T-P4S-DUL rulman resim 5
Price: 1,713.53 $
Specifications
Brand FAG
Item Number B71924-C-T-P4S-DUL FAG
Manufacturer Part Number 0380474200000
Also known as 71924CD/P4ADGA
EAN 4012801617970
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 120
Outer (D) MM 165
Width (B) MM 44
Inner (d) Inch 4.7244
Outer (D) Inch 6.4961
Width (B) Inch 1.7323
Weight (kg) 2.32 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 22
Radial Static Load Rating C0r (N) 59000
Radial Dynamic Load Rating Cr (N) 76000
Basic static load rating, radial (C 0r) "59000.0000"
Limiting speed for grease lubrication (n G Grease) 8000
Limiting speed for oil lubrication (n G Oil) 12000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B719..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL Set Of 2 Universal Bearings, Light Preload
