FAG B71922-E-T-P4S-K5-UL
Price: 818.24 $
Specifications
| Brand | FAG |
| Item Number | B71922-E-T-P4S-K5-UL FAG |
| Manufacturer Part Number | 0191549920000 |
| EAN | 4012801457996 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 110 |
| Outer (D) MM | 150 |
| Width (B) MM | 20 |
| Inner (d) Inch | 4.3307 |
| Outer (D) Inch | 5.9055 |
| Width (B) Inch | 0.7874 |
| Weight (kg) | 0.84 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | K5 - P4S + K5 |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 20 |
| Basic static load rating, radial (C 0r) | 44500 |
| Limiting speed for grease lubrication (n G Grease) | 8000 |
| Limiting speed for oil lubrication (n G Oil) | 12000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 | Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL | Single Bearing, Universal, Light Preload |
