FAG B71917-C-T-P4S-UM

FAG B71917-C-T-P4S-UM
FAG B71917-C-T-P4S-UM rulman resim 1
FAG B71917-C-T-P4S-UM rulman resim 2
FAG B71917-C-T-P4S-UM rulman resim 3
FAG B71917-C-T-P4S-UM rulman resim 4
Price: 358.29 $
Specifications
Brand FAG
Item Number B71917-C-T-P4S-UM FAG
Manufacturer Part Number 0384954810000
Also known as 71917CDGB/P4A
EAN 4026677024428
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 85
Outer (D) MM 120
Width (B) MM 18
Inner (d) Inch 3.3465
Outer (D) Inch 4.7244
Width (B) Inch 0.7087
Weight (kg) 0.53 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 18
Basic static load rating, radial (C 0r) 33500
Limiting speed for grease lubrication (n G Grease) 11000
Limiting speed for oil lubrication (n G Oil) 17000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
