FAG B71916-C-T-P4S-DUL
Price: 615.71 $
Specifications
| Brand | FAG |
| Item Number | B71916-C-T-P4S-DUL FAG |
| Manufacturer Part Number | 0191544290000 |
| Also known as |
71916CD/P4ADGA |
| EAN | 4012801457033 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 80 |
| Outer (D) MM | 110 |
| Width (B) MM | 32 |
| Inner (d) Inch | 3.1496 |
| Outer (D) Inch | 4.3307 |
| Width (B) Inch | 1.2598 |
| Weight (kg) | 0.74 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 16 |
| Radial Static Load Rating C0r (N) | 25500 |
| Radial Dynamic Load Rating Cr (N) | 35500 |
| Basic static load rating, radial (C 0r) | "25500.0000" |
| Limiting speed for grease lubrication (n G Grease) | 12000 |
| Limiting speed for oil lubrication (n G Oil) | 19000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B719..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
FAG HC71916-E-T-P4S-DBL
0.71 kg
80x110x32 mm
RHP 7916CTDULP4
0.74 kg
80x110x32 mm
SNFA SEB80 9CE1 DDL
2.96 kg
80x110x32 mm
SNFA SEB80 9 CE1 FFM
0.74 kg
80x110x32 mm
SKF 71916CD/P4ADGA
0.74 kg
80x110x32 mm
SKF 71916ACD/P4ADGA
0.74 kg
80x110x32 mm
RHP 7916CTDUMP4
0.74 kg
80x110x32 mm
SKF 71916CD/P4ADBA
0.74 kg
80x110x32 mm
SKF 71916CD/P4ADGB
0.74 kg
80x110x32 mm
SKF 71916ACE/HCP4ADGA
0.74 kg
80x110x32 mm
NSK 7916A5TRDULP3
0.74 kg
80x110x32 mm
Fafnir 3MMV9316WICRDUM
0.74 kg
80x110x32 mm
NSK 7916CTRDULP3
0.74 kg
80x110x32 mm
FAG B71916-E-T-P4S-DUL
0.74 kg
80x110x32 mm
FAG B71916-E-T-P4S-DBL
0.74 kg
80x110x32 mm
SKF S71916ACD/P4ADBC
0.76 kg
80x110x32 mm
SKF 71916ACD/P4ADGC
0.74 kg
80x110x32 mm
SNFA SEB80 7CE3 DUL
0.74 kg
80x110x32 mm
Timken 3MMV9316WICRDUM
0.74 kg
80x110x32 mm
SKF 71916CD/PA9ADBA
2.96 kg
80x110x32 mm
RHP 7916C T DUM P4
0.74 kg
80x110x32 mm
RHP 7916ETDULP4
0.74 kg
80x110x32 mm
SKF S71916ACD/HCP4ADGA
0.76 kg
80x110x32 mm
RHP 7916E T DUL P4
0.74 kg
80x110x32 mm
NSK 7916C TR DUL P3
0.74 kg
80x110x32 mm
NSK 7916A5 TR DBEL P3
0.74 kg
80x110x32 mm
FAG HCB71916-E-T-P4S-DUL
0.622 kg
80x110x32 mm
FAG HC71916-E-T-P4S-DUL
0.71 kg
80x110x32 mm
FAG B71916-E-T-P4S-DUM
0.74 kg
80x110x32 mm
FAG B71916E-T-P4S-DUL
0.74 kg
80x110x32 mm
FAG HSS71916-E-T-P4S-DBL
0.78 kg
80x110x32 mm
FAG HS71916-C-T-P4S-DUL
0.78 kg
80x110x32 mm
FAG XCS71916-E-T-P4S-DUL
0.76 kg
80x110x32 mm
FAG HSS71916-C-T-P4S-DUL
0.868 kg
80x110x32 mm
FAG HC71916E-2RSD-T-P4S-DUL
0.71 kg
80x110x32 mm
