FAG B71914-C-T-P4S-K5-UL
Price: 319.74 $
Specifications
| Brand | FAG |
| Item Number | B71914-C-T-P4S-K5-UL FAG |
| Manufacturer Part Number | 0384353140000 |
| EAN | 4012801456470 |
| Category | Angular Contact Ball Bearing Single Row |
| Outer (D) MM | 100 |
| Width (B) MM | 16 |
| Width (B) Inch | 0.6299 |
| Weight (kg) | 0.33 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | K5 - P4S + K5 |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S-K5 | Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter) |
| UL | Single Bearing, Universal, Light Preload |
