FAG B71902-E-T-P4S-UL
Price: 116.51 $
Specifications
| Brand | FAG |
| Item Number | B71902-E-T-P4S-UL FAG |
| Manufacturer Part Number | 0191534220000 |
| Also known as |
71902ACDGA/P4A |
| EAN | 4012801454100 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 15 |
| Outer (D) MM | 28 |
| Width (B) MM | 7 |
| Inner (d) Inch | 0.5906 |
| Outer (D) Inch | 1.1024 |
| Width (B) Inch | 0.2756 |
| Weight (kg) | 0.01 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 7 |
| Radial Static Load Rating C0r (N) | 1940 |
| Radial Dynamic Load Rating Cr (N) | 4850 |
| Basic static load rating, radial (C 0r) | "1940.0000" |
| Limiting speed for grease lubrication (n G Grease) | 50000 |
| Limiting speed for oil lubrication (n G Oil) | 75000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearing B719..-E-T-P4S, with steel balls |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL | Single Bearing, Universal, Light Preload |
