FAG B71900-E-T-P4S-DUM
Price: 192.54 $
Specifications
| Brand | FAG |
| Item Number | B71900-E-T-P4S-DUM FAG |
| Manufacturer Part Number | 0385715790000 |
| Also known as |
71900ACD/P4ADGB |
| EAN | 4026677488190 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 10 |
| Outer (D) MM | 22 |
| Width (B) MM | 12 |
| Inner (d) Inch | 0.3937 |
| Outer (D) Inch | 0.8661 |
| Width (B) Inch | 0.4724 |
| Weight (kg) | 0.02 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DM - 2 Univ Bearings Medium Pre |
| Lubrication | Standard Lubrication |
| Width (b) mm | 6 |
| Radial Static Load Rating C0r (N) | 1020 |
| Radial Dynamic Load Rating Cr (N) | 2900 |
| Basic static load rating, radial (C 0r) | "1020.0000" |
| Limiting speed for grease lubrication (n G Grease) | 70000 |
| Limiting speed for oil lubrication (n G Oil) | 110000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearing B719..-E-T-P4S, with steel balls |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUM | Set Of 2 Universal Bearings, Medium Preload |
