FAG B7028-E-T-P4S-UM

FAG B7028-E-T-P4S-UM
FAG B7028-E-T-P4S-UM rulman resim 1
FAG B7028-E-T-P4S-UM rulman resim 2
FAG B7028-E-T-P4S-UM rulman resim 3
FAG B7028-E-T-P4S-UM rulman resim 4
Price: 1,019.56 $
Specifications
Brand FAG
Item Number B7028-E-T-P4S-UM FAG
Manufacturer Part Number 0191529650000
Also known as 7028ACDGB/P4A
EAN 4026677568816
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 140
Outer (D) MM 210
Width (B) MM 33
Inner (d) Inch 5.5118
Outer (D) Inch 8.2677
Width (B) Inch 1.2992
Weight (kg) 3.33 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 33
Radial Static Load Rating C0r (N) 108000
Radial Dynamic Load Rating Cr (N) 145000
Basic static load rating, radial (C 0r) "108000.0000"
Limiting speed for grease lubrication (n G Grease) 5600
Limiting speed for oil lubrication (n G Oil) 9000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
