FAG B7024-E-T-P4S-DUL
Price: 1,369.51 $
Specifications
| Brand | FAG |
| Item Number | B7024-E-T-P4S-DUL FAG |
| Manufacturer Part Number | 0191527360000 |
| Also known as |
7024ACD/P4ADGA |
| EAN | 4012801452953 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 120 |
| Outer (D) MM | 180 |
| Width (B) MM | 56 |
| Inner (d) Inch | 4.7244 |
| Outer (D) Inch | 7.0866 |
| Width (B) Inch | 2.2047 |
| Weight (kg) | 4.12 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 28 |
| Radial Static Load Rating C0r (N) | 78000 |
| Radial Dynamic Load Rating Cr (N) | 109000 |
| Basic static load rating, radial (C 0r) | "78000.0000" |
| Limiting speed for grease lubrication (n G Grease) | 6700 |
| Limiting speed for oil lubrication (n G Oil) | 10000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
FAG B7024-C-T-P4S-DUL
4.14 kg
120x180x56 mm
FAG B7024-E-2RSD-T-P4S-DUL
4.12 kg
120x180x56 mm
FAG B7024-C-2RSD-T-P4S-DUL
4.14 kg
120x180x56 mm
FAG B7024-E-2RSD-T-P4S-DUM
4.12 kg
120x180x56 mm
SKF 7024CD/P4ADGB
4.2 kg
120x180x56 mm
SKF 7024ACD/P4ADGB
4.2 kg
120x180x56 mm
SKF S7024CD/P4ADGB
4.2 kg
120x180x56 mm
SKF 7024CD/P4ADBB
4.2 kg
120x180x56 mm
SKF S7024CE/P4ADGA
4.2 kg
120x180x56 mm
SNFA EX120 7CE3 T/7CE1 D/130
4.2 kg
120x180x56 mm
Koyo (JTEKT) 7024CP5FYDB/25
4.2 kg
120x180x56 mm
NSK 7024CTRDUMP3
4.2 kg
120x180x56 mm
NSK 7024CTRDULP3
4.2 kg
120x180x56 mm
SKF 7024ACD/P4ADGA
4.2 kg
120x180x56 mm
SNFA EX120 7CE3 DDM
4.2 kg
120x180x56 mm
SKF 7024C/P4DBB
4.2 kg
120x180x56 mm
SNFA EX120 7CE1 DDM
4.2 kg
120x180x56 mm
SNFA EX120 7CE3 DUL
4.2 kg
120x180x56 mm
SNFA EX120 7CE1 DDL
4.2 kg
120x180x56 mm
NSK 7024A5 TR DUL P3
4.2 kg
120x180x56 mm
RKB 7024BM DB
4.8 kg
120x180x56 mm
FAG HC7024-E-T-P4S-DUL
4.4 kg
120x180x56 mm
FAG HCRS7024-D-2RSD-T-P4S-DUL
3.56 kg
120x180x56 mm
FAG XCS7024-E-T-P4S-QUL
4.2 kg
120x180x56 mm
FAG B7024E-T-P4S-DUL
4.12 kg
120x180x56 mm
SKF 7024CD/P4ADT
4.2 kg
120x180x56 mm
SKF 7024ACD/P4ADBB
4.2 kg
120x180x56 mm
SKF S7024ACD/P4ADGC
4.2 kg
120x180x56 mm
RHP 7024A5 TR DUM P3
4.2 kg
120x180x56 mm
SKF 7024ACD/P4ADBA
4.2 kg
120x180x56 mm
SKF S7024ACE/HCP4ADGA
3.61 kg
120x180x56 mm
SKF S7024ACD/P4ADBB
4.3 kg
120x180x56 mm
SKF 7024CD/P4ADGC
4.2 kg
120x180x56 mm
SKF 7024CD/P4ADFA
4.2 kg
120x180x56 mm
RHP 7024TA DUH EP7
4.2 kg
120x180x56 mm
