FAG B7022-E-2RSD-T-P4S-K5-UL

FAG B7022-E-2RSD-T-P4S-K5-UL
FAG B7022-E-2RSD-T-P4S-K5-UL rulman resim 1
FAG B7022-E-2RSD-T-P4S-K5-UL rulman resim 2
FAG B7022-E-2RSD-T-P4S-K5-UL rulman resim 3
FAG B7022-E-2RSD-T-P4S-K5-UL rulman resim 4
Price: 906.53 $
Specifications
Brand FAG
Item Number B7022-E-2RSD-T-P4S-K5-UL FAG
Manufacturer Part Number 0388177210000
EAN 4026677935250
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 110
Outer (D) MM 170
Width (B) MM 28
Inner (d) Inch 4.3307
Outer (D) Inch 6.6929
Width (B) Inch 1.1024
Weight (kg) 1.94 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision K5 - P4S + K5
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 28
Basic static load rating, radial (C 0r) 73000
Limiting speed for grease lubrication (n G Grease) 7500
Suffix description
E 25° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S.K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL Single Bearing, Universal, Light Preload
L055 Lubrication
