FAG B7021-C-T-P4S-UL
Price: 542.71 $
Specifications
| Brand | FAG |
| Item Number | B7021-C-T-P4S-UL FAG |
| Manufacturer Part Number | 0191525400000 |
| Also known as |
7021CDGA/P4A |
| EAN | 4012801452496 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 105 |
| Outer (D) MM | 160 |
| Width (B) MM | 26 |
| Inner (d) Inch | 4.1339 |
| Outer (D) Inch | 6.2992 |
| Width (B) Inch | 1.0236 |
| Weight (kg) | 1.52 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 26 |
| Radial Static Load Rating C0r (N) | 61000 |
| Radial Dynamic Load Rating Cr (N) | 85000 |
| Basic static load rating, radial (C 0r) | "61000.0000" |
| Limiting speed for grease lubrication (n G Grease) | 8500 |
| Limiting speed for oil lubrication (n G Oil) | 13000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL | Single Bearing, Universal, Light Preload |
