FAG B7020-E-T-P4S-TUM

FAG B7020-E-T-P4S-TUM
FAG B7020-E-T-P4S-TUM rulman resim 1
FAG B7020-E-T-P4S-TUM rulman resim 2
Price: 1,688.13 $
Specifications
Brand FAG
Item Number B7020-E-T-P4S-TUM FAG
Manufacturer Part Number 0385092370000
EAN 4026677058034
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 150
Width (B) MM 72
Inner (d) Inch 3.937
Outer (D) Inch 5.9055
Width (B) Inch 2.8346
Weight (kg) 3.69 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing TU - Tripple Set, Universal, 3
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 24
Radial Static Load Rating C0r (N) 55000
Radial Dynamic Load Rating Cr (N) 79000
Basic static load rating, radial (C 0r) "55000.0000"
Limiting speed for grease lubrication (n G Grease) 8000
Limiting speed for oil lubrication (n G Oil) 13000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
TUM Set Of 3 Universal Bearings, Medium Preload
