FAG B7019-C-T-P4S-UL
Price: 454.29 $
Specifications
| Brand | FAG |
| Item Number | B7019-C-T-P4S-UL FAG |
| Manufacturer Part Number | 0191522720000 |
| Also known as |
7019CDGA/P4A |
| EAN | 4012801451840 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 95 |
| Outer (D) MM | 145 |
| Width (B) MM | 24 |
| Inner (d) Inch | 3.7402 |
| Outer (D) Inch | 5.7087 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 1.19 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 15 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 24 |
| Radial Static Load Rating C0r (N) | 54000 |
| Radial Dynamic Load Rating Cr (N) | 81000 |
| Basic static load rating, radial (C 0r) | "54000.0000" |
| Limiting speed for grease lubrication (n G Grease) | 9500 |
| Limiting speed for oil lubrication (n G Oil) | 15000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances |
| C | 15° Or 17° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| UL | Single Bearing, Universal, Light Preload |
