FAG B7018-C-T-P4S-K5-UL

Specifications

Brand	FAG
Item Number	B7018-C-T-P4S-K5-UL FAG
Manufacturer Part Number	0191521160000
EAN	4012801451604
Category	Angular Contact Ball Bearing Single Row

Weight and Dimensions

Outer (D) MM	140
Width (B) MM	24
Width (B) Inch	0.9449
Weight (kg)	1.14 kg

Product Properties

Seal	No Seal
Cage Type	TB - Hard Fiber Cage
Precision	K5 - P4S + K5
Contact Angle	15 degrees
Pairing	G - Universal Pairing
Axial Internal Clearance / Preload	UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication	Standard Lubrication

Data from Schaeffler (medias)

Medias description

Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances

Suffix description

C	15° Or 17° Contact Angle
T	Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5	Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UL	Single Bearing, Universal, Light Preload
